Product details
Sartorius BioWelder TC 1 Welding Device automated tube welder, an operator inserts the tube holders, the disposable blade and the TPE tubes and initiates the welding process via the touch screen. The blade is first heated for depyrogenation and cooled to the welding temperature, with an infrared sensor controlling the temperature
| Automated & ergonomic design | On-screen step-by-step instructions, color coding and size-specific tube holders minimize operator errors. |
| Variety of qualified materials | Compatible with Tuflux TPE, C-Flex 374*, AdvantaFlex**, PharMed* BPT, and SaniPure* BDF™ tubings. Additional TPE brands may be used after internal validation. |
| Variety of tube sizes and conditions | Has 1/4″ to 1″ OD tube size capacity and can weld dry, wet or liquid-filled tubes. |
| Extensively qualified | Comprehensive validation guide is available to support quality assurance and safe and robust sterile welding connections. |
| Short welding time | Produces fast, reliable and automated connections in under 2.5 minutes. |
Description :
- Tubing compatibility: TPE tubing, 1/4″ to 1″ (6.4 to 25.4mm) OD
- Welding time: 1.5 to 2.5 minutes
- Operating temp: +5C to +40C
- Dimensions: 10″W x 21″D x 10″H
- Compatible tubing materials: TuFlux TPE, C-Flex 374, AdvantaFlex, PharMed BPT & SaniPure BDF
- Fully automated with touchscreen control
- 100-240VAC 50/60Hz
