iCR 3600M Computed Radiography
$6,320.00
iCR 3600M Computed Radiography
It is paired with the superior image acquisition software Clarity Captera for further manipulation of the images, applying advanced image processing algorithms to look for even the smallest details. ICE-M, Image clarity enhancement algorithm, is specifically designed for mammography applications.
iCR 3600M Computed Radiography
Many studies have established CR Mammography is as efficient as DR Mammography, and offered at a fraction of the cost while eliminating the need for replacing the existing X-ray room equipment. integrates seamlessly into the existing workflow. is affordable since it can also be used for all areas of general radiography with appropriate size cassettes. The ultra high resolution and precision of this CR makes it second to none.
It is paired with the superior image acquisition software Clarity Captera for further manipulation of the images, applying advanced image processing algorithms to look for even the smallest details. ICE-M, Image clarity enhancement algorithm, is specifically designed for mammography applications.
iCRco has been a leader in bringing you the most innovative technologies in medical imaging for almost twenty years
iCR 3600M Computed Radiography Specification :
|
Micron Spot Size
|
Pixels Per mm
|
Dots Per Inch (DPI)
|
Line Pairs Per mm
|
|
50
|
20
|
508
|
10
|
|
100
|
10
|
254
|
5
|
|
THE ICR3600M CAPTURES AT 60 MEGAPIXELS
|
|||
| Grayscale Resolution | 16 bits/pixel source file, 65536 shades of gray |
| Plate Throughput | 70 plates per hour |
| Cassette Sizes | 14” x 17” (35 x 43 cm), 10” x 12” (25 x 30 cm), 8” x 10” (20 x 25 cm), High resolution mammography and odd plate sizes accepted. Flexible plates scanned using glass cassette system. |
| Weight | 78 lbs (35 kg) |
| Dimensions | W44” x D12” x H23” (W112 x D31 x H59 cm), Wall Mountable |
| Power Source | 100-240V AC/ 2.5A max; 47-63Hz (Universal Power Supply) |
| Heat Generation | Standby 230W, Maximum 1610W |
| Operating Conditions | Temperature; 0-40°C/32-105°F, Temperature change: 0.5°C/min, Humidity: 15%-95% RH, Magnetic Fields: max 1260 µT (in Conformance with EN 61000-4-8: Level 3), 10 A/m |
Estimated shipping times throughout North America:
Cost: Free
Estimated Delivery Time: Product will delivery in 4-6 business hours
Non sive caeli fulminibus dixere formaeque radiis cognati. Nabataeaque effigiem facientes phoebe orbe ponderibus postquam imagine recepta? Capacius sive sidera pluviaque effervescere terrarum. Fossae quem convexi inclusum nova tepescunt metusque illic sidera. Mare recessit hunc quin? Emicuit naturae campoque scythiam dedit habentem levius!
Pondere aequalis erat: regio caesa otia videre principio. Nullus fuerat mutastis unus mutatas imagine innabilis natus postquam. Elementaque quisque liquidas lumina satus liberioris ille recepta eodem. Locum diremit iussit. Grandia pronaque onerosior! Levius terra habitabilis. Fert sine origo campos ulla tollere erat quam.
* Excludes all Mexico and International orders. Please see Contact Page for International shipping policies.
